20FT Skeleton Container Chassis Semi Trailer
20FT Skeleton Container Chassis Semi Trailer, bulk powder tanker type, 30–60CBM optional volume, BOHAI/KEFA double-cylinder compressor and WEICHAI diesel engine, for cement, lime and dry powder transport, JOST landing gear and WABCO brake system.
联系我们获取价格
对本产品感兴趣？立即联系我们获取详细价格与产品信息。
Product Overview
The 20FT Skeleton Container Chassis Semi Trailer is a powder bulk tanker built on 20ft skeleton chassis. It is designed for pneumatic delivery of dry powder materials such as cement and lime. The tank is constructed from high-strength wear-resistant steel, powered by BOHAI/KEFA 12m³ double-cylinder air compressor and WEICHAI diesel engine. Equipped with heavy-duty mechanical suspension, JOST landing gear and WABCO brake parts, it is reliable for building material yards, cement plants and mine logistics.
Key Features
- Customizable Dimension: Standard size 11000×2500×3650mm, available for customized design.
- Durable Tank Construction: 5mm high-strength wear-resistant steel for tank material, 3.5mm tank wall thickness.
- Wide Volume Selection: Tank volume optional from 30CBM to 60CBM.
- Independent Pneumatic Discharge System: BOHAI/KEFA 12m³ double cylinder air compressor driven by WEICHAI diesel engine.
- Heavy-duty Running Gear: 3 axles with heavy-duty mechanical suspension, adapted to complex road conditions.
- Complete Accessories: 2 spare tire racks and 1 set tool box.
- Overseas Standard Configuration: JOST landing gear, WABCO brake system, 24V LED lights for overseas market.
- High-quality Polyurethane Coating: Excellent anti-corrosion and anti-rust property for longer service life.
- Dimension(L*W*H)：11000*2500*3650 mm, customized sizes or designed according to customers’ needs
- Tanker body material：5mm high strength wear-resistance steel
- Volume：30CBM To 60CBM
- Axles：3 axles
- Tire：12 units
- Application：BOHAI/KEFA brand, for transport lime, cement, powder etc.
- Tank body thickness：3.5mm
- Compressor：BOHAI/KEFA brand 12m³ double cylinder air compressor
- Spare tire rack：2 units
- Diesel Engine：WEICHAI Brand
- Suspension：Heavy duty mechanical suspension
- Landing gear：JOST
- Brake system：WABCO
- Light：LED light, specially intended for oversea markets
- Voltage：24V
- Tool box：1 set
- Painting：Polyurethane paint, with long service life, anti-rust performance
This 20ft skeleton chassis powder tanker semi trailer adopts pneumatic unloading structure, suitable for transporting cement, lime, fly ash and other dry powder bulk materials. The tank capacity and overall dimensions can be customized to match different logistics requirements.
