50T 3 Axles Cement Bulk Pneumatic Tanker Trailer
50T three-axle cement bulk pneumatic tanker trailer, optional tank capacity from 30CBM to 60CBM, equipped with BOHAI/KEFA double-cylinder air compressor and WEICHAI diesel engine, for pneumatic delivery of cement, lime and other dry powder materials, fitted with JOST landing gear and WABCO brake system.
联系我们获取价格
对本产品感兴趣？立即联系我们获取详细价格与产品信息。
Product Overview
The 50T 3 Axles Cement Bulk Pneumatic Tanker Trailer is a heavy-duty pneumatic powder transport tanker with 50 tons rated load capacity. Its standard overall dimension is 11000×2500×3650mm, and the tank volume is optional from 30CBM to 60CBM. The tank body is made of high-strength wear-resistant steel, matched with BOHAI/KEFA 12m³ double-cylinder air compressor and WEICHAI diesel engine for stable pneumatic discharging. Equipped with heavy-duty mechanical suspension, JOST landing gear and WABCO brake assembly, it is widely applied in cement plants, concrete mixing stations and bulk building material logistics.
Key Features
- 50T Heavy Load Design: Reinforced chassis for high-capacity powder bulk transport.
- Customizable Dimension: Standard size 11000×2500×3650mm, support customized design.
- Durable Tank Construction: 5mm high-strength wear-resistant steel, tank wall thickness 3.5mm.
- Flexible Volume Range: Tank capacity optional between 30CBM and 60CBM.
- Stable Pneumatic Discharge System: BOHAI/KEFA 12m³ double cylinder air compressor driven by WEICHAI diesel engine.
- Heavy-duty Running Gear: 3 axles with heavy-duty mechanical suspension, adapting to complex road conditions.
- Complete Accessories: 2 spare tire racks and 1 set tool box.
- Overseas Standard Configuration: JOST landing gear, WABCO brake system, 24V LED lights for overseas markets.
- High-performance Polyurethane Paint: Good anti-corrosion and anti-rust ability to extend service life.
- Rated Load: 50T
- Dimension(L*W*H)：11000*2500*3650 mm, customized sizes or designed according to customers’ needs
- Tanker body material：5mm high strength wear-resistance steel
- Volume：30CBM To 60CBM
- Axles：3 axles
- Tire：12 units
- Application：BOHAI/KEFA brand, for transporting lime, cement, powder etc.
- Tank body thickness：3.5mm
- Compressor：BOHAI/KEFA brand 12m³ double cylinder air compressor
- Spare tire rack：2 units
- Diesel Engine：WEICHAI Brand
- Suspension：Heavy duty mechanical suspension
- Landing gear：JOST
- Brake system：WABCO
- Light：LED light, specially intended for oversea markets
- Voltage：24V
- Tool box：1 set
- Painting：Polyurethane paint, with long service life, anti-rust performance
This 50-ton bulk cement pneumatic tanker semi trailer adopts pneumatic unloading design. It is mainly used for transporting cement, lime, fly ash and other dry powder bulk cargo. Tank volume and overall dimensions can be customized to meet different bulk powder transportation requirements.
