Side Fence Cargo Animal Transport Livestock Semi Trailer with Stake
Side Fence Livestock Semi Trailer with stakes, 60 ton payload, specially designed for animal transportation, 4 pcs 13T FUWA/BPW axles, JOST kingpin and landing gear, WABCO overseas brake valve, also available for bulk cargo hauling.
联系我们获取价格
对本产品感兴趣？立即联系我们获取详细价格与产品信息。
Product Overview
The Side Fence Cargo Animal Transport Livestock Semi Trailer with Stake is a professional livestock transport trailer. Its standard dimension is 13000×2500×3000mm with 60-ton payload. The open stake fence design ensures good air circulation to keep animals comfortable and safe during transportation. Equipped with four 13-ton FUWA/BPW heavy axles, JOST coupling components and WABCO overseas-spec brake system, this trailer is durable and stable for farm and ranch logistics.
Key Features
- Customizable Size & Fence Height: Standard dimension 13000×2500×3000mm, fence height 1400mm, adjustable as customer requirements.
- Ventilated Stake Fence for Livestock: Open fence structure provides good airflow, ideal for cattle, sheep, pig and other animal transport.
- Heavy Load Capacity: Rated payload up to 60 tons.
- 4 Heavy-duty Axles: 4 pcs 13T FUWA or BPW axles for reliable heavy-load performance.
- Multiple Suspension Options: Mechanical suspension, bogie suspension or airbag suspension for different road surfaces.
- Famous Brand Fittings: JOST 2.0/3.5 inch kingpin (bolted or welded optional) and JOST C200T landing gear.
- Anti-slip Deck: 3mm thick checkered plate bottom platform, wear-resistant.
- Oversea Standard Brake System: WABCO RE6 relay valve for overseas market, TKL T30/30+T30 spring brake chamber and 45L air tank; ABS optional.
- Complete 24V Electrical System: ISO 7-pin socket, full set of signal lights and 6-core standard cable.
- Anti-corrosion Painting Process: SA2.5 sandblasting pretreatment, two anti-corrosion primer coats plus one finish coat.
- Standard Accessories: Tool box and full set of maintenance tools.
- Dimension(mm): 13000x2500x3000mm, customized sizes or designed according to customers’ needs
- Trailer Sides: 1400mm height, customized by you
- Loading capacity(ton): 60T
- Axles: 4 axles, 13T, FUWA / BPW Brand
- Tire: 12 units, 12.00R22.5 or 315/80R22.5
- Suspension: Mechanical / Bogie / Airbag suspension
- King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)
- Landing Gear: JOST brand C200T
- Bottom Platform: 3mm-thick checkered plate
- Brake Chamber: WABCO RE 6 relay valves; T30/30+T30 spring braking chamber (TKL brand), 45L air tank
- Valve: WABCO valve, specially intended for oversea market
- ABS: Optional
- Electric system: One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable
- Painting: S.A.2.5 standard sandblasting; Two coat of anti-corrosion prime; one coat of finish painting
- Accessory: One tool box; one set of standard tools
This stake side fence semi trailer is mainly built for livestock and animal transportation such as cattle, sheep and pigs. The fence structure guarantees ventilation and safety during transit. It can also be used to transport grain and other bulk goods. Size and fence height can be customized.
